3-CONTROLSANDINSTRUMENTS
Fueltankllerpump(ifequipped)
WARNING
Firehazard!
Whenhandlingdieselfuel,observethefollowingprecautions:
1.Donotsmoke.
2.Neverllthetankwhentheengineisrunning.
3.Wipeupspilledfuelimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W0099A
NOTICE:Donotputamoistureeliminationproduct(waterdrainingagent)inthefueltank.Itmaydamagetheengine.
NOTICE:Thefueltankllerpumpislocatedinsidethecompartmentontherightfrontoftheupperstructureandshall
beusedforfuelonly.Usesuitablefuel.
1.Parkthemachineonat,horizontalground,stopthe
engineandturnthestarterkeytoONposition.
2.Taketheinletpipeoutoftheright-handcompartment.
SMIL17CEX0210AA1
3.Measuretheheightofthedrumandplacetheidenti-
cationclamp(1)ofthesuctiontubeatalengthslightly
lessthanthatofthedrumheight.
4.Makesurethattheendstrainerofthesuctiontubeis
correctlyattachedandtheninsertthesuctiontubein
thedrum.
SMIL14CEX2515AB2
5.Removethefueltankllercap.
WARNING
Burnhazard!
Ifthellercapremainsonduringtherefuel-
ingprocess,removingthecapafterrefueling
couldcauseanaccident.Toreducethisrisk,
ALWAYSremovethefueltankllercapbefore
refuelingwiththefueltankllingpump.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0247A
SMIL17CEX3250AA3
3-77
