CASE CONSTRUCTION CX145D SR - Every 2000 Hours; Hydraulic Oil Suction Filter

6-MAINTENANCE
Every2000hours
Hydraulicoilsuctionlter
WARNING
Burnhazard!
Beforeperforminganyserviceonthehydraulicsystem,youmustallowittocool.Hydraulicuid
temperatureshouldnotexceed40°C(104°F).
Failuretocomplycouldresultindeathorseriousinjury.
W0241A
WARNING
Pressurizedsystem!
Neverattempttodrainuidsorremovelterswhentheengineisrunning.Turnofftheengineand
relieveallpressurefrompressurizedsystemsbeforeservicingthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0905A
Cleanthehydraulicoilsuctionlterevery2000h
NOTICE:Ifanyattachmentotherthanabucketisused,reducetheintervalofthehydraulicoilsuctionltercleaning.
RefertoChapter9.
NOTICE:Ifyoundanymetalparticlesontheoldlters,consulttheCASECONSTRUCTIONdealer.
NOTICE:Replacethehydraulicoilsuctionlterevery5000hofoperationorwhenhydraulicuidisreplaced.
1.Releaseallthepressureinthehydraulictank.Referto
page6-10.
2.Removethepaneloverthehydraulictank.Cleanthe
topsurfaceofthehydraulictank.
3.Removethecover(1),theO-ring(2),andthespring(3)
locatedontopoftherodassemblyofthesuctionlter.
4.Removetheoilsuctionlter(4),andcleanitwitha
solvent.
Letitdrycompletely,andcheckfordamage.Ifany
damageisfoundonitssurface,replaceitwithanew
component.
5.AttachanewO-ring(2),andattachthesuctionlter(4),
thespring(3),andtherodassembly.
6.Attachthecover(1).
7.Checkthehydraulicuidlevel,andsupplyitifneces-
sary.
8.Installthepaneloverthehydraulictank.
SMIL17CEX3546BA1
6-55
