CASE CONSTRUCTION CX145D SR - Engine Hood; Lower Panels

3-CONTROLSANDINSTRUMENTS
Enginehood
WARNING
Rotatingparts!
Shutofftheenginebeforeopeningtheenginehood.
Failuretocomplycouldresultindeathorseriousinjury.
W1059A
WARNING
Fallingobjecthazard!
RiskofinjuryfromFALLINGENGINEHOOD.Latchthehoodinthefullyopenpositionpriortoworking
withintheenginecompartment.
Failuretocomplycouldresultindeathorseriousinjury.
W1090B
Opening
Unlockthelatcheswiththestarterkey.Disengagethe
latches,andraisetheenginehooduntilitisxedinthe
openpositionwiththestay.
NOTICE:Afterfullyopeningtheenginehood,checkthat
itisxedrmly.
NOTICE:Donotopentheenginehoodduringstrong
winds.
SMIL17CEX3243AA1
Closing
Raisealittletheenginehoodinordertounlockthestay.
Handlethestaytoleaditintotheguide,andthengen-
tlylowerthehood.Asthehoodisclosed,engagethe
latchesrmly,andlockthemwiththestarterkey.
SMIL17CEX3242AA2
Lowerpanels
WARNING
Movingparts!
Makesurethelowerpanelsareproperly
closedbeforedrivingthemachine.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0910A
Locatedonthebottomsideoftheupperframe.Thelower
panelsgiveaccesstotheengineoildrainplug,tothe
hydraulictankdrainplug,tothefueltankdrainplug.
SMIL17CEX3241AA1
3-73
