CASE CONSTRUCTION CX145D SR - Replacement of Belt; Hydraulic Oil Tank

6-MAINTENANCE
Replacementofbelt
NOTICE:Ifthebeltbreaks,themessageALTERNATORisdisplayed.Stoptheengine,removethestarterkey,and
thenreplacethebelt.
1.Loosenthelocknut(1)andthemountingbolt(2).
2.Lightlytightenthelocknut(1)untilitsseatingface
touches.
3.Removethebeltfromthepulleytopullitoutfrom
cutoutportionofthefanguide.
4.Insertthenewbeltfromthefanguidetomount
itbyaligningittogrooveofeachpulley.Rotate
theadjustbolt(3)toadjusttensionofthebeltto
becomestandardvalue.
5.Tightenthelocknut(1)andthemountingbolt(2)
thathavebeenloosenedwithspeciedtorque.
6.Afteradjustment,runtheengineinidlingspeedfor
approximately5min,andthenstoptheengineto
re-checktensionofthebelt.
SMIL15CEX9110AB4
Hydraulicoiltank
WARNING
Burnhazard!
Beforeperforminganyserviceonthehydraulicsystem,youmustallowittocool.Hydraulicuid
temperatureshouldnotexceed40°C(104°F).
Failuretocomplycouldresultindeathorseriousinjury.
W0241A
Drainwaterandsedimentfromthehydraulicoiltankevery250h
1.Releaseallthepressureinthehydraulictank.Referto
page6-10.
2.Placeareceptacleofasuitablecapacityunderthe
drainplug.
3.Openthedrainplugonthebottomofthetankanddrain
thesedimentandwateraccumulatedatthebottomof
thetank.
4.Afterdraining,closethedrainplug.
5.Addhydraulicoilifnecessary.
SMIL17CEX3267AA1
6-35
