3-CONTROLSANDINSTRUMENTS

Whenthemachineisequippedwiththeauxiliarylow-ow

hydrauliccircuit,theleft-handcontrolleverincludes:

1.Proportionalswitchtooperatedouble-actinghydraulic

attachments.

2.ON/OFFbuttontooperatethepreferredoperatingdi-

rectionofthedouble-actinghydraulicattachment.

3.Hornbutton.

SMIL15CEXY839BA2

3-14
