4-OPERATINGINSTRUCTIONS

7.Removethestarterkey,getoffthecabandlockthe

cabdoor.Checkthatthehoodandthesidedoorsare

properlylocked,andthatthelowerpanelsareproperly

xed.

NOTE:Makesurethatanyportionofthemachineisin-

terferingpublicroad.Installappropriatetrafcsignsifany

portioninterferespublicroad.

GHN2P4-005A4

4-20
