3-CONTROLSANDINSTRUMENTS
Themirrorshallbepositionedaccordingtothereferencesshowninpicture:
Thesideontherearleftofthemachineshallbevisible.
Theareaaroundareferencebodypositioned1m(39.4in)backfromtheedgeofthelefttrack(A)and1m(39.4in)
leftwardthemachine(B)shallbevisible.
SMIL17CEX3657GA4
NOTICE:Afterinstallingandpositioningallthemirrors,thevisibilityaroundthemachineshallbecheckedfromthe
operator'sseat.Settheseatintothedesiredposition,andmakesuretoconrmallthereferenceviewsinthemirrors.
Ifnecessary,netunethepositioningofthemirrorsinordertoensurepropervisibilityaroundthemachine.
