6-MAINTENANCE

8.TurnthestarterkeytoOFFposition.

9.Switchthevalveofthefuelmainltertotheengine

side.

SMIL17CEX3819AA4

10.Wipeallthespilledfuelcompletely.Starttheengine

tocheckforleaks.Wipeallthespilledfuelcom-

pletely.Otherwise,aremaybecaused.

6-12
