6-MAINTENANCE

Boomcylinderbottompin:twogreasettings.

SMIL17CEX3573AA3

Boom/armlinkage:onegreasetting.

SMIL17CEX3569AA4

Armcylindertoppin:onegreasetting.

SMIL17CEX3570AA5

Armlink/Connectingrod:fourgreasettings.

NOTICE:thearmlinkandtheconnectingrodshallbelu-

bricatedevery10hifanyattachmentotherthanabucket

isused.

SMIL14CEX2732AA6

6-46
