6-MAINTENANCE

5.Loosenthecoolantdrainplugontherightsideofthe

engineblock.Draincoolantinsidetheengine.

6.Closethecoolantdraincockoftheradiator.

NOTICE:Thecoolantdraincockoftheradiatorshouldbe

tightenedbyhand.Itmaybedamagedifbeingtightened

withtoolssuchaspliers.

7.Closethecoolantdrainplugontheengineblock.

NOTICE:theengineshallneverbestartedwithnowater

intheradiator.Thiscausestheenginetoseizeup.

NOTICE:thedrainedcoolantshallbedisposedaccording

tothelocalRegulationsforcoolantuids.

SMIL17CEX3571AA3

6-60
