6-MAINTENANCE

Upperstructureandcabheadlight:

1.Openthefrontright-handdooruntilitisxedbythe

stay.

SMIL17CEX3246AA5

2.Removetherightfrontcover.

SMIL17CEX0138AA6

3.Disconnecttheplug.

SMIL13CEX2833AB7

4.Removethefourscrewsandtilttheheadlight.

SMIL13CEX2834AB8

6-76
