6-MAINTENANCE
SMIL17CEX0556FA2
Fusefunctions
Fusebox(1)Fusebox(2)
(F1)Keyswitch10A(F1)SeatHeater10A
(F2)Accessories10A(F2)Wiperandwasher15A
(F3)GPScontroller10A(F3)Cigarlighter10A
(F4)ICTcontroller15A(F4)DCconverter10A
(F5)Monitor10A(F5)Fieldviewmonitor10A
(F6)Controller10A(F6)Spare10A
(F7)Gatelocklever10A(F7)Beacon10A
(F8)Airconditionerunit5A(F8)Lamp(cab)15A
(F9)Airconditionerblowermotor15A(F9)Lamp(boom,housing)15A
(F10)Airconditionercompressor5A(F10)Optionline10A
(F11)Enginecontroller20A(F11)Spare10A
(F12)Backup(monitor)10A(F12)Indicator10A
(F13)Backup(radio)10A(F13)Optionalcontroller10A
(F14)Solenoid15A(F14)Optionalcontroller15A
(F15)Proportionalsolenoid15A
(F16)Horn10A
NOTE:ifCASECONSTRUCTIONSiteWatch™Telematicssystemisequipped,adedicated5Afuseisaddedout-
sideofthemainfusebox.Thefuseconnectorislocatedunderneaththepanelsbehindtheoperator'sseat.
6-84
