9-ACCESSORIES
Auxiliarylow-owhydrauliccircuit
Themachinecanbeequippedwithanadditionallow-owauxiliaryhydrauliccircuittooperateattachmentsfeaturing
secondaryhydraulicactuationforpositioning,suchasrotatinggrabsortiltablebuckets.
Hydraulicconnections
Thefeedvalvesatthetopofthearmallowtoinstallproperlyandsafelythehosestoconnectthehydraulicattachment
tothelinesoftheauxiliarylow-owhydrauliccircuit.
SMIL15CEXY958FB10
Open/Closetool(A)
19mmwrench
Hydraulicconnection(B)G1/2”femaleportwithO-Ringseat
NOTE:themaximumowrateoftheauxiliarylow-owhydrauliccircuitusingtheSPworkmodeis56L/min(14.8US
gpm).Themaximumworkingpressureoftheauxiliarylow-owhydrauliccircuitis20.6MPa(2988psi).
NOTE:anadditionaldrainageline(D)islocatedontheleftsideofthearm.Thedrainageline(D)isintendedtoallow
externaldrainagefromthehydraulicmotorwhichrotatesthegraborthecrusher.
NOTICE:Alwayskeepeachconnectinghoseonthesamesideofthearm.Nevercross-overtheconnectinghoses
betweenthetwosidesofthearm.
9-10
