9-ACCESSORIES
5.Operatethearmandbucketcontrolssoastobringthe
quickcouplerhook(2)aroundtheattachmentpin(3).
SMIL13CEX2698AB3
6.Operatethebucketcontrolleversothatthepiniscom-
pletelyengagedinthequickcouplerhook.
SMIL13CEX2699AB4
7.Operatethearmcontroltoraisethearmandoperate
thebucketcontroltoextendthebucketcylinderrod
completely.
SMIL13CEX2700AB5
8.Raisethearmuntiltheattachmentpinisvisiblefrom
theoperator’sseat.
NOTICE:Thequickcouplerextendsthelengthofthearm
andwithcertainattachmentsthereistherisktohitthe
cabinsomeoperatingpositions.Withthiskindofattach-
ments,itmaynotbepossibletoraisethearmuntilthe
attachmentpinisvisiblefromtheoperator'sseat.
SMIL13CEX2701AB6
9-24
