9-ACCESSORIES

Thecamerapositionmonitorallowstocheckifthecam-

erasareproperlyxedandorientedtoensurethecom-

prehensivevisualizationoftheareaaroundthemachine.

Ifthelines(A)areprojectedoverthehatchedarea,the

camerasareproperlyxedandoriented.

Ifanyofthelines(A)isnotprojectedoverthehatched

area,thecamerasarenotproperlyxedandoriented.

Stopmachineoperation,andrequesttheCASECON-

STRUCTIONdealertoadjustthecameras.

NOTICE:Neveroperatethemachineifthecamerasare

notproperlyxedandoriented.Operatinginsuchcondi-

tionmayleadtoseriousinjuriestothebystanders.

SMIL17CEX0430BA5

9-37
