Chapter VII Removal and Installation of Instrument Panel &
Instrument Panel Crossbeam
I. Removal of Instrument Panel
Tools: 8 #sleeve, extension bar, 飞扳[MS1], cross head screwdriver,
flat head screwdriver, etc.
1. Removal Steps
1.1. Open the storage box over the console, and use a cross head
screwdriver to loosen off the two screws. Then use a flat head
screwdriver to pry open the storage box. See the right figure:
1.2. Use a cross head screwdriver to loosen off the two screws than
connect the emergency switch with the Instrument Panel, as shown
in the figure:
1.3. Pull out the top part by hand, and then use a flat head
screwdriver to pry open the lower part. Unplug the harness when
removing it, as shown in the figure:
