III. Instructions on Main Connectors
No
Connector Name Pins
Connection Remark
1
License plate lights connector 2 License plate lights harness
2
Left-rear combination tail light connector 10 Left-rear combination tail light harness
3
Trunk light connector 2 Trunk light harness
4
Left-rear speaker connector 2 Left-rear speaker harness
5
Fuel pump connector 4 Fuel pump harness
6
Right-rear speaker connector 2 Right-rear speaker harness
7
Right-rear combination tail tights connector
6 Right-rear combination tail lights harness
8
BCM Module A connector
BCM Module B connector
16
25
BCM Module A harness
BCM Module B harness
9
Hand brake switch connector 1 Hand brake switch harness
10
Ceiling light connector 6 Ceiling light harness
11
Seat belt switch connector 2 Seat belt switch harness
12
Connect the instrument harness butt joint 26 Butt jointed with instrument harness
13
Butt jointed with instrument harness 4 Butt jointed with instrument harness
14
To front compartment harness connector 16 To front compartment harness
15
Left-rear wheel ABS sensor connector 2 Left-rear wheel ABS sensor harness
16
Right-rear wheel ABS sensor connector 2 Right-rear wheel ABS sensor harness
17
Reverse radar power connector 2 Reverse radar power harness
18
Butt jointed with tail door harness 6 Butt jointed with tail door harness
19
Ground 1 Connected with ground wire
Inside the left C-pillar
inner shield
20
Left-rear door contact switch connector 1 Left-rear door contact switch harness
21
Right-rear door contact switch connector 1 Right-rear door contact switch harness
22
Ground 1 Connected with ground wire
Inside the right C-pillar
inner shield
23
Connector to front door harness butt joint 1
10
Front door harness butt joint 1
24
Connector to front door harness butt joint 2 14
Front door harness butt joint 2
25
Connector to interior and right-front door
butt joint 1
6 Interior and right-front door butt joint 1
26
Connector to interior and right-front door
butt joint 2
10
Interior and right-front door butt joint 2
27
Right-front door contact switch connector 1 Right-front door contact switch harness
28
Left-front door contact switch connector 1 Left-front door contact switch harness
29
Forming butt-joint with left-rear door
harness
10
Forming butt-joint with left-rear door
harness
30
Interior forming butt-joint with right-rear
door
10
Interior forming butt-joint with right-rear
door
31
Ground 1 Connected with ground wire
In the carpet under
below left A-pillar
32
Ground 1 Connected with ground wire
On the left of BCM
module box
33
Ground 1 Connected with ground wire
In the left ceiling
handle
34
Dormer controllerconnector 6 Sunroof controller harness
