4.1.4 Pry out the rear coil spring with screwdriver.
4.1.5 Vibrate from side to side with force with hand to remove the
rear bumper block.
4.2 Cross Stay Assembly
4.2.1 Remove the connecting bolts of cross stay and left side of
vehicle body with 16# socket.
Torque: 100±10 Nm
4.2.2 Remove the connecting bolts of cross stay and right side of
vehicle body with 15# socket to remove the cross stay assembly.
Torque: 100±10 Nm
4.3 Rear Trailing Arm Assembly
4.3.1 Remove the connecting bolts from the rear side of rear axle
and trailing arm assembly with 13# socket.
Torque: 100±10 Nm
