5.1.4. Remove the spoiler.
5.1.5. Pull off the rear water nozzle (You can pry with a flat head
screwdriver, but try to avoid any paint scratch), and then pull off the
water nozzle hose.
5.2. Installation Steps
The installation steps are reverse to those for removal.
Note: Water injection opening should be opposite to wiper motor
steering shaft.
6. Removal of Rear Wiper Motor
6.1. Removal Steps
6.1.1. Remove the rear wiper shield by hand.
6.1.2. Use a 10# sleeve wrench to loosen off the nut above the
motor, and remove the rear wiper blade.
Installation torque is 12±2Nm
