Chapter IV Removal, Installation & Maintenance of Front/Rear
Bumper
I. Removal, Installation & Maintenance of
Front Bumper
1. Preparations
Tools: 8# wrench, 8#sleeve, cross head screwdriver, flat head
screwdriver
Spare parts: disposable clips
2. Notes
2.1. Please wear necessary labor protection supplies to avoid
accidents.
2.2. Try to avoid scratching the painted surface of the bumper during
the removal operation.
2.3. For removal in colder environment, operate gently to avoid
damaging the bumper.
3. Removal Steps
(Take the left side as an example)
3.1 Open the Front Hood.
3.2 Remove the headlights. (See Removal and Installation of
Headlights)
3.3 Use a cross head screwdriver to loosen off the four screws on the
grid fence.
3.4. Use a 8# sleeve wrench to loosen off the two bolts on the
bumper and the left wing sheet.
Torque: 11N·m
3.5. Use a cross head screwdriver to loosen off the 7 screws on the
bumper and the front compartment member.
