2. Removal and Installation of Blower Speed Regulation Module
2.1. Removal Steps
2.1.1. Pull out the speed regulation module plug.
2.1.2. Use a cross head screwdriver to loosen off the 2 fixing screws
on Speed Regulation Module.
2.1.3. Pull out the speed regulation module.
2.2. Installation Steps
The installation steps are reverse to those for removal.
3. Removal and Installation of Heater Exchanger
3.1. Removal Steps
3.1.1. Disassemble the evaporator assembly. (See Removal of
Evaporator Assembly)
3.1.2. Disassemble the air-conditioner harness. (See Removal of
Air-conditioner Harness)
3.1.3. Loosen off the two fixing screws and remove the heater
exchanger shield.
