III. Removal and Installation of Battery Harness
Part number: S12-3703010AC
(I). Preparations
Tools: 10#. 13# wrench
(II). Notes
Make sure to disconnect the power supply when disassembling the
electrical components and harnesses.
Ignition switch must be OFF.
(III). Removal Steps
1. Removal
1.1. Use a 10# wrench to remove the battery positive.
1.2. Use a 10# wrench to loosen off the battery negative.
1.3. Use a 13# wrench to loosen off the battery negative harness
Remove the battery negative harness at the vehicle body ground
wire.
2. Installation
The installation steps are reverse to those for removal.
