The breakdown illustration of steering gear is shown below:
1 – Lock nuts 2 – Track rod 3 – Input shaft 4 – Left installation bracket 5 – Right installation
bracket
The illustration of steering universal joint and protective sleeve is shown below:
2. Preparations
Tools: 13#, 19# socket wrench, 12#, 13#, 17# non-adjustable wrench.
Accessories: power steering fluid
3. Notices
3.1. Please wear necessary labor insurance products in order to avoid the accidents.
3.2 Avoid steering fluid to contact with skin or eyes when disassembling steering system.
S21-3404060
(Steering universal knuckle
protective sleeve assembly)
