4.6 Remove the fixing screws above the left bracket of power
steering gear with 13# socket.
Torque: 100±10 Nm
4.7 Remove the fixing screws under the left bracket of power
steering gear with 13# socket.
Torque: 100±10 Nm
4.8 Remove the fixing bolts of the steering universal joint with 10#
socket wrench to remove the steering gear assembly.
5. Installation Procedure
Refer to removal procedures.
