Chery A113 - Instructions on Main Connectors

112
II. Instructions on Main Connectors
No Connector Name Pins Connection Remark
1 In-door harness connector 16 In-door harness
2 Instrument harness A
connector
26 Instrument harness A
3 Instrument harness B
connector
4 Instrument harness B
4 Washing fluid piping
5 ABS connector 25 ABS
6 Ground A Vehicle body ABS on the left-front
side member
7 Left-front combination
headlights connector
10 Left-front combination
headlights
8 Fuse box Fuse box
9 Anti-theft speakerconnector 2 Anti-theft speaker
10 Connect the battery Battery
11 Engine harness connector 16 Engine harness
12 Brake fluid level sensor
connector
2 Brake fluid level
sensor
13 Front wiper motor connector 4 Front wiper motor
14 Left-front wheel ABS sensor
connector
2 Left-front wheel ABS
sensor
15 Left turning light connector 2 Left turning light
16 Fan motor 1 connector 3 Fan motor 1
17 Fan motor 2 connector 3 Fan motor 2
18 Ground B Vehicle body Fan on the left-front side
member
19 Left-front fog lights
connector
2 Left-front fog lights
20 Speaker 1 connector 2 Speaker 1
21 Speaker 2 connector 2 Speaker 2
22 Front compartment contact
switch connector
3 Front compartment
contact switch
23 Ground C Vehicle body Washer solution tank on
the right-front side
member
24 Right-front fog light
connector
2 Left-front fog light
25 Front washing motor
connector
2 Front washing motor
26 Rear washing motor
connector
2 Rear washing motor
27 Washing fluid pipe
28 Right turning light
connector
2 Left turning light
29 Right-front combination
headlight connector
10 Right-front
combination headlight
30 Right-front wheel ABS
sensor connector
2 Right-front wheel ABS
sensor
31 Air-conditioner high/low
voltage switch connector
4 Air-conditioner
high/low voltage
switch
