III. Engine Compartment Dimensions
No Name Diameter
A/B Front bumper crossbeam mounting hole Φ11
C/D/E/F Headlight mounting hole Φ7
G/H Engine right suspension bracket mounting hole Φ13
I/J Installation of fender Φ8
K/L Shock absorber mounting hole Φ76
