II. Instructions on Main Connectors
III. Removal and Installation of Right-front Door In-door Harness
Part number: S21-3724080
1. Removal
See Removal of Left-front Door In-door harness.
2. Installation
The installation steps are reverse to those for removal.
No Connector Name Pins Connection Remark
1 Right-front door in-door harness
connector
16 In-door harness
2 Right-front window motor connector 2 Right-front window motor
3 Right-front window switch connector 10 Right front window switch
4 Right-front door lock connector 4 Right-front door lock
5 Right-front speaker connector 2 Right-front speaker
6 Power rearview mirror motor / right
turning light connector
6 Power rearview mirror motor /
right turning light
To Next Page
