1.6. Use a 10# wrench to disassemble the two bolts of the ground
wire earth at the places as shown in the figure.
1.7. Loosen off the single bolt and four nuts on the side pillars (See
Chassis Maintenance Manual: side pillars), and then relase the side
pillar.
1.8. Disassemble all harness plugs that are connected with the
Instrument Panel crossbeam. For example, the harness plug of the
brake light switch.
1.9. Take out the Instrument Panel crossbeam.
2. Installation Steps
The installation steps are reverse to those for removal.
