1.10. Disassemble the auxiliary Instrument Panel (See Chapter I
Removal, Installation & Adjustment of of the Brake System).
1.11. Use a cross head screwdriver to pry open the decoration sheet
on the ash tray and take it out.
1.12. Use a cross head screwdriver to loosen off the four screws that
connect the cigarette lighter with the Instrument Panel, and unplug
the harness when removing the lighter.
1.13. Use a cross head screwdriver to loosen off the three screws
that connects the ashtray with the Instrument Panel and take out the
ashtray.
Note: When disassembling the console, the operations should be
carried out from top to bottom, and you should disassemble the
air-conditioner switch before disassembling the audio system.
