101
2.13. Clearance between gas tank cover and rear fender (side wall) at 17-17 and 18-18:
5.0
0
4
+
mm
2.14. Clearance between rear bumper and rear fender at 19-19:
5.0
0
0
+
mm
加油口盖
后翼子板
后翼子板
后保险杠
Rear fender
Gas tank cover
Rear fender
Rear bumper
