Chery A113 - Page 191

18 C212 instrument to
engine connector
1 Instrument electric device box
C211
1 Instrument panel to plug
2 Instrument panel to plug
3 Instrument panel to plug
4 Instrument panel to plug
5 Instrument panel to plug
6 Instrument panel to plug
7 Instrument panel to plug
8 Headlight switch
9 Nightlight switch
10 Brake light switch
11 Air-conditioner thermostat
12 Air-conditioner thermostat
13 Brake light switch
19 C209 instrument to
engine connector
14
Anti
-
sheft module
1 Instrument electric device box
2 Ground
3 ——
4 Ignition switch(IGN1)
5
C209〔instrument to engine〕
6 ——
7
Failure diagnosis socket →
instrument panel plug
20 Anti-sheft module
connector
8
C20〔instrument to engine〕
1 C200 (instrument to interior )
2 C100 (instrument to front
compartment )
3 Ignition switch(IGN2)
4 C100 (instrument to front
compartment )
5 C100(instrument to front
compartment )
6 Wiper relay
7 Wiper relay
8 Ignition switch(IGN2)
21 Wiper switch
connector
9 C100 instrument to front
compartment
