Chery A113 - Page 193

1
Blower switch →
air-conditioner reconditionang
2 Inside/outside circulation
motor
3 Inside/outside circulation
motor
4 ——
5 C100(instrument to front
compartment )
6 Blower relay
7 ——
8 Ground
9 ——
10 C200 (instrument to interior )
11 Ignition switch(IGN2)
12 ——
13 ——
14 ——
15 To instrument electric box
29 Air-conditioner switch
connector
16
——
1 Ground wire
2 Ignition switch(ACC)
30 Cigar lighter
3
C200 (instrument to interior )
1 Ignition switch(IGN1)
2 Instrument panel plug
3 Instrument panel plug
4 ——
5 C200(instrument to interior )
31 Air bag connector
6
Trouble diagnosis socket
1 ——
2 ——
3 ——
4 Ground
5 Ground
6 ——
7 Anti-sheft module connector
Instrument panel plug
C200(instrument to interior )
C100(instrument to front
compartment )
Air bag
8 ——
9 ——
10 ——
11 ——
12 ——
32 Trouble diagnosis
socket
13
——
