Chroma 11210 - Results of Integration Test Example

Battery Cell Insulation Tester 11210 User’s Manual
8-8
This example set the PD Interval to 0.4s, thus the number of times is computed as below:
VPD: (2s / 0.4s) + 1 = 6 times
CPD: (2s + 2s) / 0.4 = 10 times
8.3.2 Results of Integration Test Example
Parameter
Default Value
Result
11210
Test Voltage
500V
11210 measure:
VPD Times = 6
VPD Level = 27~33
CPD Times = 10
VPD Level = 27~33
Note:
VPD Times =
Charge Time
PD Interval
+ 1
CPD Times =
Dwell Time + Test Time
PD Interval
Charge Current
1mA
LC Range
20mA
Trigger Mode
Manual
Integration Time
1PLC
Charge Time
2000ms
Dwell Time
2000ms
Test Time
2000ms
VPD Level
1
VPD Level
1
A112102
Voltage Trigger
20V
PD Interval
0.4s
PD Capacitance
#5
Partial Discharge
Multiple
