Battery Cell Insulation Tester 11210 User’s Manual
9-2
Partial discharge detection pass.
16
/PD_Fail
Output (O/P)
Low
Partial discharge detection fail
17 /FAIL Output (O/P) Low
Total FAIL contains Compare fail, Contact
check fail, Charge/Discharge fail or Partial
discharge detection fail.
18
/EOT
Output (O/P)
Low
End of Test
19 /HI Output (O/P) Low
1. LC test value is higher than the high
limit; IR test value is lower than the low
limit.
2. The test voltage is abnormal or the
measured current is out of the
measurement range in test time during
test procedure.
3. The WV actual voltage is larger than
the set voltage.
20,24
X
-
N.C
21 /LO Output (O/P) Low
LC test value is lower than the low limit; IR
test value is higher than the high limit.
22 /ACQ Output (O/P) Low
Analog acquisition end, move the next DUT
to test terminal of 11210. Refer nACQ
Activation setting in SYSTEM CONFIG.
23
/FAIL_CHG_D
ISCHG
Output (O/P) Low
1. Charge or discharge fails
2. WV discharge fails
Table 9-1 I/O Interface Control Signal Table
9.2 Reference Table of Handler Interface Signal
Result
/PASS /FAIL
/HI :
(L.C. High)
(I.R. Low)
/LO
(L.C. Low)
(I.R. High)
/FAIL_CHG
_DISCHG
/C_CHK
FAIL
/PD_FAIL Reserve
Total Pass
●
○
○
○
○
○
○
○
Charge Fail
○
●
○
○
●
○
○
○
Overload
○
●
●
○
○
○
○
○
High
○
●
●
○
○
○
○
○
Low
○
●
○
●
○
○
○
○
Contact
Check Fail
○ ● ○ ○ ○ ● ○ ○
Partial
Discharge
Fail
○ ● ○ ○ ○ ○ ● ○
AUTO
RANGE
Fail
○ ● ○ ○ ○ ○ ○ ○
