Chroma 11210 User Manual

Specification Verification Procedure
A-1
Appendix A Specification Verification
Procedure
The specification calibration procedure described in this chapter is providing the 11210
Battery Cell Insulation Tester for using function specification verification. The procedure is
applicable to verification of new purchased instrument, verification after troubleshooting and
instrument calibration periodically.
To conduct the specification verification procedure in this chapter should be a qualified
verification personnel who has the relevant power measurement expertise and need to
familiar with the test device used in this chapter. To avoid the damage caused by electric
shock during operation.
Only the qualified personnel can execute procedures described in this
chapter to verify the tester to avoid electric shock.
A.1 Hardware Requirement
This section required test equipment are listed as below:
Test Device
Recommended Product Model
Remark
Digit Multimeter 6 1/2
Keysight 34461A or Agilent 34401A
Digit Multimeter 8 1/2 Keysight 3458A
Can be measured
under 1nA
Test cable
11210 standard accessory (BNC test cable
+ HV test cable)
Guard line
Use with Keysight 3458A measuring line
LC resistance fixture
200MΩ / 20MΩ / 2MΩ / 200kΩ / 20kΩ / 2kΩ
If there is no identical test device, at least the same level or above is
configured.
A.2 DCV (Voltage Source and Voltage Meter)
Specification verification for voltage source and voltage list:
Output Specifications
Output Voltage
1.0V ~ 100V, step 0.1V
Accuracy: ±(0.5% Setting + 1% Range)
101V ~ 1000V, step 1V
Accuracy: ±(0.5% Setting + 0.5% Range)
Measurement Display Range- Basic Measurement Accuracy
Vmea
100V
±(0.3% Reading + 0.3% Range)
1000V
±(0.3% Reading + 0.3% Range)
CAUTION
CAUTION
