Battery Cell Insulation Tester 11210 User’s Manual
1-2
(8) Partial Discharge Function (Option)
Partial Discharge Tester: Partial Discharge Voltage/Current Level & Times Test
Partial Discharge Analyzer: Partial Discharge Voltage/Current Curve Plotting & Analysis
Partial Discharge Tester Checking Kit
1.3 Checking before Use
Before shipment, this instrument was inspected and found to be free of mechanical and
electrical defects. As soon as the instrument is unpacked, inspect for any damage that may
have occurred in transit. Save all packing materials in case the instrument has to be returned.
If damage is found, please file claim with carrier immediately. Do not return the instrument to
Chroma without prior approval.
Upon receipt of the instrument, please check on the following items:
(1) If there are any damages or scratches on the product surface.
(2) The standard and optional accessories came with the instrument as listed in Table 1-1.
WIRE BANA.PLUG/Alligator Clip to Red
High Voltage Cable for 90 CM
1 A test cable
Test Cable BNC + Alligator Clip 1M
For power supply AC 230V use
For power supply AC 115V use
User’s Manual CD 1
CD for user’s manuals in English,
Traditional Chinese and Simplified Chinese
Table 1-1 Model 11210 Standard Accessories
A11200/A112101 Quick Start Guide
Table 1-2 Model A112100 Standard Accessories
A11200/A112101 Quick Start Guide
Table 1-3 Model A112101 Standard Accessories
XHM-5000 Red High Voltage Cable 15 CM
A112102 Quick Start Guide
Table 1-4 Model A112102 Standard Accessories
Only name item is required when ordering any of the accessories.
