Battery Cell Insulation Tester 11210 User’s Manual
2-2
• Temperature: 23ºC ± 5ºC
• Relative Humidity: 75% maximum
• Warm up: 30 minutes minimum
• Test condition for accuracy specification: measurement speed with integration time of
500ms.
• Guarantee only for the tests on pure resistive DUT.
Accuracy of IR measurement:
It is calculated based on the accuracy of leakage current measurement and voltage
measurement. For detailed descriptions, see Appendix B IR Accuracy.
2.1.4 Display Range
Parameter
Range
Leakage Current
00.00 nA ∼ 20.00 mA
Insulation Resistance
0.01 KΩ ∼ 10 TΩ
2.1.5 Measurement Time
Line Frequency Setting
Integration Time
50Hz
1 ms
4 ms
1PLC(20 ms)
100 ms
500 ms
5ms ~ 9.999s
60Hz
1 ms
4 ms
1PLC(17ms)
100 ms
500 ms
5ms ~ 9.999s
2.1.6 Test Time
Test Condition
Test Time Setting
Charge
0.005s ~ 99.999s, step 0.001s
Dwell
0.005s ~ 99.999s, step 0.001s
Test
0.005s ~ 99.999s, step 0.001s
Accuracy <1 ms
2.1.7 LC Null
It eliminates the leakage current of the entire measuring loop to add the measurement
accuracy before connecting DUT for test.
2.1.8 Contact Check
Make sure the leakage current test end of the tester and DUT are connected.
