Battery Cell Insulation Tester 11210 User’s Manual
10-20
STATUS:OPERation:NTRansition
It sets negative transition register of operation. If the register is set to 1, the status register
of operation is from 1 changed to 0 thus signal register of operation will be set. Please
refer STATUs:OPERation:PTRansition command.
Set command format: STATUs:OPERation:NTRansition <NR1>
Parameter: <NR1>, the range is 0~32767.
Query command format: STATUs:OPERation:NTRansition?
Return data: <NR1>
STATUS:OPERation:PTRansition
It sets positive transition register of operation. If the register is set to 1, the status register
of operation is from 0 changed to 1 thus signal register of operation will be set. Please
refer to STATUs:OPERation:NTRansition command.
Set command format: STATUs:OPERation:PTRansition <NR1>
Parameter: <NR1>, the range is 0~32767.
Query command format: STATUs:OPERation:PTRansition?
Return data: <NR1>
STATUS:OPERation:PRESet
It sets various registers of operation to preset status; the settings of various registers are
given as the following.
Set ENABle bit to 0’s.
Set PTRansition bit to 1’s.
Set NTRansition bit to 0’s.
Set command format: STATUs:PRESet
STATUS:QUEStionable:CONDition?
It queries questionable condition register.
Query command format: STATUs: QUEStionable:CONDition?
Return data: <NR1>
STATUS:QUEStionable:ENABle
It sets questionable enable register.
Set command format: STATUs:QUEStionable:ENABle <NR1>
Parameter: <NR1>, the range is 0~32767.
Query command format: STATUs:OPERation:ENABle?
Return data: <NR1>
STATUS:QUEStionable?
It queries questionable event register.
Query command format: STATUs:QUEStionable [:EVENt]?
Return data: <NR1>
Bit
Position
15-8 7 6 5 4 3 2 1 0
Condition
Reserved,
unused
Reserved,
unused
Reserved,
unused
Reserved,
unused
System
Error
Inter
Lock
Error
FAN
Lock
Error
OTP
Error
STATUS:QUEStionable:NTRansition
It sets negative transition register of questionable. If the register is set to 1, the status
register of questionable is from 1 changed to 0 thus signal register of questionable will be
set. Please refer to STATus: QUEStionable:PTRansition command.
Set command format: STATUs:QUEStionable:NTRansition <NR1>
Parameter: <NR1>, the range is 0~32767
