Battery Cell Insulation Tester 11210 User’s Manual
5-18
Once entering power-on self test screen, display if the currently status of tester and calibration
data inside the tester is operating normally.
Test Item
Description
Pass/Installed
Fail/No Install
Measurement Unit
Measurement unit
check
Function normally
Function abnormally, user
can’t conduct measurement.
Memory Check
Memory check
Memory normally
Memory abnormally,
measurement module can’t
be used.
Calibration Data
Calibration data check
Calibration data
normally
Calibration data read back
abnormally, it will cause
serious error when measuring
and should be returned to
Chroma for calibration as
soon as possible. But it still
can perform measurement.
System Fan
Fan operation aging
check
Fan operation
normally
The fan has an aging
phenomenon and should be
returned to Chroma as soon
as possible, but it still can be
used.
PD Tester
PD test functions
Installed
No install
PD Analyzer
PD analysis functions
Installed
No install
