Cisco ASR 5000 Series

Cabling the Gigabit Ethernet Line Cards
Quad Gigabit Ethernet Line Card (QGLC) ▀
ASR 5000 Installation Guide ▄
131
Table 41. SFP Modules Supported by the QGLC
Module Type
Card Identification
Interface Type
Cable Specifications
1000Base-SX
Ethernet 1000 SX
Fiber, LC duplex
female connector
Fiber Type: Multi-mode fiber (MMF), 850 nm wavelength
Core Size (microns)/Range:
 62.5/902.23 feet (275 meters)
 50/1640.42 feet (500 meters)
Minimum Tx Power: -9.5 dBm
Rx Sensitivity: -17 dBm
1000Base-LX
Ethernet 1000 LX
Fiber, LC duplex
female connector
Fiber Type: Single-mode fiber (SMF), 1310 nm wavelength
Core Size (microns)/Range: 9/32808.4 feet (10 Kilometers)
Minimum Tx Power: -9.5 dBm
Rx Sensitivity: -19 dBm
1000Base-T
Ethernet 1000 Copper
RJ-45
Operates in full-duplex up to 100 meters of CAT-5 shielded
twisted pair (STP) cable with BER less than 10e-10.
NOTE: To comply with GR-1089 intra-building, lightning-
immunity requirements and ensure compliance with Radiated
Emissions Criteria, you must use shielded-twisted pair cable
and ensure that it is properly terminated at both ends.
Important: The SFP interface is only certified to work with SFP transceiver modules purchased from Cisco for
use with the QGLC.
Important: Because of the optical SFP interface, this product has been tested and found to comply with the limits
for Class 1 laser devices for IEC825, EN60825, and 21CFR1040 specifications.
