Cisco ASR 5000 Series Installation Guide

Cabling the Gigabit Ethernet Line Cards
▀ Cabling the Optical SFP+ Interface
▄ ASR 5000 Installation Guide
136
Cabling the Optical SFP+ Interface
To interconnect the optical SFP+ interface on the XGLC, follow the instructions below.
Important: Be sure to label the interface cable with its destination prior to connecting it to the XGLC. This will
assure proper reconnection should the card need to be serviced.
WARNING: Only trained and qualified personnel should install, replace, or service this equipment.
WARNING: Invisible laser radiation may be emitted from the aperture of the port when no cable is connected.
Avoid exposure to laser radiation and do not look into open apertures. Be sure to keep the cover on the interface
when it is not in use.
WARNING: Laser Klasse 1 - nur speziell ausgebildetes Personal darf dieses Geraet warten. Nicht in den Laser
schauen, um Augenverletzungen zu vermeiden. Nicht genutzte Buchsen mit der entsprechenden Kappe verschliessen.
Step 1 Remove the cover from the SFP interface.
Step 2 Insert the optical cable from a network device into the interface and ensure that it is securely in place.
