ASR 5000 Hardware Platform Overview
â–„ ASR 5000 Installation Guide
Table 11. FLC2 Callouts
Card Ejector Levers—Use to insert/remove card to/from chassis.
Interlock Switch—In its Down position the interlock switch notifies the system to safely power down the card prior to
its removal.
Card Level Status LEDs—Show the status of the card.
RJ-45 10/100 Ethernet Interfaces—Eight auto-sensing RJ-45 interfaces for R-P interface connectivity carrying user
data. Ports are numbered 1 through 8 from top to bottom.
Gigabit Ethernet Line Card (GLC2)
The GLC2 installs directly behind its respective packet processing card, providing network connectivity to the packet
data network. The GLC2 (Ethernet 1000) supports a variety of 1000 Mbps optical and copper interfaces based on the
type of Small Form-factor Pluggable (SFP) modules installed on the card.
Important: The GELC has reached its end of life and is no longer available for purchase. It has been replaced by
the GLC2.
Table 12. SFP Modules Supported by the GLC2
Fiber, LC duplex
female connector
Fiber Type: Multi-mode fiber (MMF), 850 nm wavelength
Core Size (microns)/Range:
ï‚· 62.5/902 feet (275 meters)
ï‚· 50/1640 feet (500 meters)
Minimum Tx Power: -9.5 dBm
Rx Sensitivity: -17 dBm
Fiber, LC duplex
female connector
Fiber Type: Single-mode fiber (SMF), 1310 nm wavelength
Core Size (microns)/Range: 9/32808 feet (10 kilometers)
Minimum Tx Power: -9.5 dBm
Rx Sensitivity: -19 dBm
Operates in full-duplex up to 100 meters of CAT-5 Shielded
Twisted Pair (STP) cable with BER less than 10e-10.
Important: This product has been tested and found to comply with the limits for Class 1 laser devices for
IEC825, EN60825, and 21CFR1040 specifications.
