Cabling the Gigabit Ethernet Line Cards

▀ 10 Gigabit Ethernet Line Card (XGLC)

▄ ASR 5000 Installation Guide

134

10 Gigabit Ethernet Line Card (XGLC)

The 10 Gigabit Ethernet Line Card or XGLC, is a full-height line card. The XGLC uses industry standard SFP+

transceiver modules to support various fiber types as required. The following diagram shows the XGLC’s single SFP+

interface.

Figure 46. XGLC Fiber Optic Interface
