Application Card Installation
Installing Application Cards â–€
ASR 5000 Installation Guide â–„
Installing Application Cards
The installation procedure is identical for all application cards. This section provides the instructions for installing
application cards in the chassis.
Caution: During installation, maintenance, and/or removal, wear grounding wrist and/or heel straps to avoid
ESD damage to the components. Failure to do so could result in damage to electrical components and could potentially
void your warranty.
Step 1 Determine the type of application card you are installing. Each application card is identified by the text near the bottom
of its front panel.
Step 2 Determine which chassis slot to install the card in based on the information in Chassis Slot Numbering and
Assignments.
Step 3 Remove the blanking panel, if one is installed, covering the slot.
Step a Use a Phillips #2 screwdriver to loosen the screws at the top and bottom of the blanking panel.
Step b Holding the screws on the blanking panel, pull the blanking panel away from the chassis to expose
the chassis slot.
Step 4 Slide the interlock switch on the card fully downward and flip both ejector levers fully outward and away from the front
panel.
