Cisco ASR 5000 Series Installation Guide

Cabling the Channelized Line Cards
▀ Channelized Line Card Interfaces
▄ ASR 5000 Installation Guide
142
Channelized Line Card Interfaces
The CLC2 card supports two types of Small Form-factor Pluggable (SFP) transceiver modules. The type of optical fiber
interface on the line card is dictated by the SFP modules installed on the card. The SFP modules are hot-pluggable.
Table 45. SFP Modules Supported by the CLC2
Module Type
Card Identification
Interface Type
Cable Specifications
Single-mode
Optical Fiber
Channelized (STM-1/OC-3)
SM IR-1
Single-mode Fiber, LC
duplex female connector
Fiber Types: Single-mode optical fiber
Wavelength: 1310 nm
Core Size: 9 micrometers
Cladding Diameter: 125 micrometers
Range: Intermediate/21 kilometers
Attenuation: 0.25 dB/KM
Min/Max Tx Power: -15 dBm/-8 dBm
Rx Sensitivity: -28 dBm
Multi-mode
Optical Fiber
Channelized (STM-1/OC-3)
Multi-Mode
Multi-mode Fiber, LC
duplex female connector
Fiber Types: Multi-mode optical fiber
Wavelength: 1310 nm
Core Size: 62.5 micrometers
Cladding Diameter: 125 micrometers
Range: Short/2 kilometers
Min/Max Tx Power: -19 dBm/-14 dBm
Rx Sensitivity: -30 dBm
Important: The SFP interface is only certified to work with SFP transceiver modules purchased from Cisco for
use with the CLC2.
Important: Because of the optical SFP interface, this product has been tested and found to comply with the limits
for Class 1 laser devices for IEC825, EN60825, and 21CFR1040 specifications.
The following figure shows the LC-connectors for the CLC2. Each SFP fiber interface provides both transmit (TX) and
receive (RX) on the port.
