Cisco ASR 5000 Series Installation Guide

Technical Specifications
▀ Physical Dimensions
▄ ASR 5000 Installation Guide
258
Physical Dimensions
The ASR 5000 can be mounted in any standard (EIA-310-D, IEC 60297) 19-inch (482.6 mm) equipment cabinet or
telecommunications rack. The table below lists the dimensions for the chassis and each component that can be placed
within the chassis.
Table 85. Physical Dimensions - ASR 5000 Chassis and Components
Component
Height
Width
Depth
Chassis
24.50 in. (62.23 cm)
17.5 in. (44.45 cm)
24.0 in. (60.96 cm)
Application Card
17.05 in. (46.31 cm)
1.01in. (2.56 cm)
14.10 in. (35.81cm)
Line Card (half-height)
8.59 in. (21.82 cm)
1.01in. (2.56 cm)
5.24 in. (13.31cm)
XGLC (full-height)
17.48 in. (44.40 cm)
1.01in. (2.56 cm)
5.24 in. (13.31cm)
Fan Tray (Lower)
2.50 in. (6.35 cm)
16.25 in. (41.27 cm)
17.25 in. (43.82 cm)
Fan Tray (Upper)
2.875 in. (7.30 cm)
16.25 in. (41.27 cm)
19.375 in. (49.21 cm)
Power Filtering Unit (PFU)
3.6 in. (9.14 cm)
8.25 in. (20.96 cm)
5.12 in. (13.00 cm)
