Cisco ASR 5000 Series Installation Guide

Technical Specifications
Interface Specifications ▀
ASR 5000 Installation Guide ▄
275
Channelized Line Cards
Channelized Line Card (CLC2) with Single-Mode Interface
The optical SFP interface on the 4-port CLC2 with the single-mode interface has four pairs of connectors that accept
SFP transceivers.
Table 104. Single-Mode Fiber Transmit and Receive Levels
Signal
Level
Max TX:
-8 dBm
Min TX:
-15 dBm
Max RX:
-8 dBm (saturation average power)
Min RX:
-28 (max.) dBm (sensitivity average power)
Channelized Line Cards (CLC2) with Multi-Mode Interface
The fiber SFP interface on the 4-port CLC2 with the multi-mode interface has four pairs of connectors that receive SFP
transceivers.
Table 105. Multi-Mode Fiber Transmit and Receive Levels
Signal
Level
Max TX:
-14 dBm
Min TX:
-19 dBm
Max RX:
-12 dBm (saturation average power)
Min RX:
-30 (max.) dBm (sensitivity average power)
