Cabling the Gigabit Ethernet Line Cards
Cabling the Optical SFP Interface â–€
ASR 5000 Installation Guide â–„
Cabling the Optical SFP Interface
To interconnect the optical SFP interface(s) on the GLC2 and the QGLC, follow the instructions below.
Step 1 To ensure full connectivity, use your thumb to firmly press the SFP transceiver module into its socket on the front panel
of the card.
Step 2 Remove the cover from the SFP interface.
Step 3 Inspect and clean the connector’s fiber-optic end-faces.
Step 4 Insert the optical cable from a network device into the interface and ensure that it is securely in place.
Step 5 Repeat step 1 through step 5 to connect a fiber-optic cable to other ports, if so equipped.
