Adding Application and Line Cards to an Existing Installation
Adding a 10 Gigabit Ethernet Line Card â–€
ASR 5000 Installation Guide â–„
Important: You must slide the interlock switch upward before securing the card’s top screw to the mounting
rail.
Step 6 Use a Phillips #2 screwdriver to tighten the screws at the top and bottom of the front panel to secure the card to the
chassis.
Step 7 Repeat step 1 through step 10 for every other line card that to be installed.
Step 8 Proceed to the appropriate chapter for information on connecting data cables to the line cards.
