Replacing Upper or Lower Fan Tray

Determining Whether a Fan Tray Needs Replacing ▀

ASR 5000 Installation Guide ▄

231

SNMP Trap

Description

starFanSpeed

The speed of the fans controlled by this fan controller.

The value normal(1) represents the normal operating speed of the fans. The value high(2) represents that

the fans are running at a higher rate of speed.
